14.95 USD

TEKTRONIX entitled “TROUBLESHOOTING YOUR OSCILLOSCOPE - GETTING DOWN TO BASICS” (94 pages).

TABLE OF CONTENTS

Chapter 1 - TROUBLESHOOTING TECHNIQUES AND PROCEDURES

Chapter 2 - TROUBLESHOOTING YOUR OSCILLOSCOPE
ˇ Front Panel Diagnosis
ˇ Isolating the Faulty Section
ˇ The Basic Oscilloscope
ˇ The Power Supply
ˇ The Vertical Section
ˇ The Horizontal Section
ˇ Portable Oscilloscope Tips and Techniques
ˇ Microprocessor Based Portable Oscilloscope Tips and Techniques
ˇ Lab Instrument Oscilloscope Techniques

Chapter 3 - TROUBLESHOOTING THE POWER SUPPLY
ˇ Checking Power Supply Regulation
ˇ Resistance Measurements
ˇ Transistor Supplies
ˇ Common Power Supply Problems

Chapter 4 - TROUBLESHOOTING THE HIGH-EFFICIENCY POWER SUPPLY
ˇ The High-Efficiency Power Supply
ˇ Guidelines for Troubleshooting the High-Efficiency Supply
ˇ Typical High-Efficiency Supply Problems

Chapter 5 - TROUBLESHOOTING THE CRT AND Z-AXIS SECTION
ˇ The High Voltage Supplies
ˇ Typical High voltage Problems
ˇ CRT Conditions

Chapter 6 - TROUBLESHOOTING THE VERTICAL SECTION
ˇ Isolating Faulty Preamplifiers
ˇ Isolating Faults in the Verticals Laboratory Oscilloscopes
ˇ Troubleshooting Tips for the Vertical Section
ˇ Common Mode Operation
ˇ Tracking Down a Noisy Circuit

Chapter 7 - TROUBLESHOOTING THE HORIZONTAL SECTION
ˇ Isolating the Horizontal Amplifier
ˇ Lab Instruments Oscilloscope Tips and Techniques
ˇ Typical Horizontal Problems
ˇ Isolating Faults in the Time Base
ˇ Timebase Sequence
ˇ Tips for Troubleshooting Trigger Circuits
ˇ Tunnel Diode Triggering
ˇ Trigger Operation
ˇ Tips for Troubleshooting the Sweep Circuits
ˇ Typical Sweep Problems

The original book was scanned and converted into this digital file in Adobe Acrobat .pdf format. In order to view this file you will need to have Adobe Acrobat Reader installed on your computer.

---

Keywords: antique vintage radio oscilloscope
File Size: 0 KBytes
